| SL No. | Battery Type | Volt | Plate Per Cell | Capacity @20hrs |
Dimension in mm/inc | Approx. Wt(kgs) |
Electrolyte (Liters) |
Terminal Type | Handle | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| L | W | H | |||||||||
| 1 | N100 | 12 | 17 | 110 | 412/16.2 | 175/6.9 | 237/9.3 | 22.00 | 8.50 | R | DH/RH |
| 2 | N100Z | 12 | 19 | 115 | 412/16.2 | 175/6.8 | 237/9.3 | 22.20 | 8.50 | R | DH/RH |
| 3 | N120 | 12 | 21 | 150 | 510/20.1 | 180/7.1 | 235/9.8 | 25.50 | 12.00 | L/R | RH |
| 4 | N150 | 12 | 25 | 180 | 510/20.1 | 220/8.7 | 235/9.8 | 33 | 15.00 | L/R | RH |
| 5 | N 200 S | 12 | 27 | 180 | 510/20.1 | 270/10.6 | 235/9.8 | 33 | 21.00 | L/R | RH |
| 6 | N175 | 12 | 27 | 195 | 510/20.1 | 220/10.6 | 235/9.8 | 36.50 | 18.00 | L/R | RH |
| 7 | N200 | 12 | 29 | 210 | 510/20.1 | 270/10.6 | 235/9.8 | 38.00 | 19.20 | L/R | RH |
Designed for heavy cranking load.
Highly responsive to load in idle condition.
Low requirement of regularly topping up.
Perfect Design for Highest Capacity.
Specially designed for Ship, Steamer, launch and generator.
Eighteen Months Warranty.
Robust Construction and high Resale value.
a) Terminal Types:L=Nut-Bolt type,R=Round Post.
b) Handle:WH=Without Handle,DH=Drop Handle,RH=Rope Handle,CH=Cover Handle.
| For which application it is required | Selected Types of Battery | Capacity @20hrs |
Plate | Avg. lifetime(In case of proper selection & maintenance) | Warranty Period |
R.C | C.A |
|---|---|---|---|---|---|---|---|
| (1) Ship: Mother vessel,Cargo vessel, Launch,Steamer. (2) Different Engine capacity of Generator. (3) High capacity engine cranking ampere like 330A to 630A.For 4000cc to 8000cc. |
N100 | 110 | 17 | 24 Months To 30 Months |
18 Months | 230 | 330 |
| N100Z | 115 | 19 | 18 Months | 240 | 345 | N120 | 150 | 21 | 18 Months | 320 | 450 |
| N150 | 180 | 25 | 18 Months | 370 | 540 | ||
| N 200 S | 180 | 27 | 18 Months | 380 | 540 | ||
| N175 | 195 | 27 | 18 Months | 408 | 585 | ||
| N200 | 210 | 29 | 18 Months | 440 | 630 |
